Main Technical Parameters
Parameter | Typical Range |
Product Type | Billet / Bloom / Slab |
Number of Strands | 1 – 8 Strands |
Annual Production Capacity | 50,000 – 3,000,000 t/year |
Casting Radius | 4 – 15 m |
Casting Speed | 0.5 – 6.0 m/min |
Billet Section | 80×80 – 250×250 mm |
Bloom Section | 250×300 – 600×800 mm |
Slab Thickness | 100 – 350 mm |
Slab Width | 600 – 2,500 mm |
Mould Length | 700 – 1,200 mm |
Oscillation Frequency | 60 – 400 cpm |
Oscillation Stroke | 2 – 12 mm |
Secondary Cooling Type | Air-Mist / Water Spray |
Strand Withdrawal Force | According to Design |
Straightening Mode | Continuous / Multi-point |
Cutting System | Torch / Hydraulic Shear |
Automation Level | PLC / Level 1 / Level 2 |
Casting Steel Grade | Carbon Steel, Alloy Steel, Stainless Steel |
Yield Rate | ≥95% |
Typical CCM Sizes
Capacity | Strand No. | Product |
100,000 t/y | 1 – 2 | Billet |
300,000 t/y | 2 – 4 | Billet |
600,000 t/y | 4 – 6 | Billet/Bloom |
1,000,000 t/y | 4 – 6 | Bloom/Slab |
3,000,000 t/y | 6 – 8 | Slab |
Scope of Supply
Mechanical Equipment
· Tundish Car
· Mould Assembly
· Oscillation System
· Segment Assembly
· Dummy Bar System
· Withdrawal & Straightening Unit
· Cutting Machine
Process Systems
· Secondary Cooling System
· Mould Cooling System
· Lubrication System
Electrical Equipment
· Drive System
· PLC & Automation System
· Instrumentation System
Auxiliary Systems
· Water Treatment System
· Spare Parts Package
